一款采用Amlogic S922X芯片方案的4K智能网络播放器，采用六核心设计，堪称2019年性能最强的机顶盒产品，支持全格式的4K视频硬解码。标准版运行纯净版安卓9.0系统，用户可自由拓展软件功能。此款S922X方案的网络播放器在无线方面也十分突出。内置蓝牙5.0模块，支持超低功耗技术。内置双工双频WiFi模块，其吞吐量可超过800M。内置千兆网卡，支持USB3.0支持SATA接口。
我们专业从事方案运作，可根据用户需求定制产品，目前基于S922X芯片的消费级产品已经量产，接受行业客户的ODM定制需求。
| Hardware Specs: | ||
| Operation System | Android 9.0 | |
| Language | English, Chinese …Multi-Language support | |
| CPU | Amlogic S922X with 12nn 2.0G HZ，Quad core ARM Cortex-A73 and dual-core ARM Cortex-A53 CPU | |
| GPU | ARM Mali TM-G52 MP6(6ppc) | |
| SDRAM | DDR4 2GB (for OEM orders 3GB-4GB) | |
| Storage Capacity (Flash) | 16GB （EMMC） (compatibility 8GB-32GB) | |
| WIFI | 2.4G+5G SISO Receiver The wireless module complies with IEEE 802.11 a/b/g/n/ac 2×2 MIMO standard and it can achieve up to a speed of 867Mbps with dual stream in 802.11n to connect the wireless LAN |
|
| WIFI Module | AmPack 6398S | |
| Bluetooth | Bluetooth 5.0 with LE technology | |
| The Extended Storage | TF Card, up to 32GB (SD2.X,SD3.X,SD4.X, eMMC ver5.0) | |
| Power Supply | DC 12V/2A | |
| HDR | Support | |
| Interfaces: | ||
| HDMI Output | HDMI (2.1 and 2.0 ) to support maximum 4K@60fps output(HDCP2.2) | |
| USB Port | 1*USB 3.0 Fast Speed, 3*USB 2.0 Host | |
| Led Work Light | Support | |
| Network | 1*RJ45 1000M (1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII interface) |
|
| Power Supply | 1*DC Jack | |
| SATA | Option | |
| Media Parameter: | ||
| Audio Container | MP3,AAC,WMA,RM,FLAC,OGG | |
| Audio Out | Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing I2S audio interface supporting 2-channel input and 8-channel (7.1) output Built-in serial digital audio SPDIF/IEC958 output and PCM input/output Built-in stereo audio DAC, Stereo digital microphone PDM input Support concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM |
|
| Video CODEC | VP9 Profile-2 up to 4Kx2K@60fps H.265 HEVCMP-10@L5.1 up to 4K*2K@60fps H.264 AVC HP@L5.1 up to4K*2K@60fps H2.64 MVC up to1080P@60fps MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) WMV/VC-1 5P/MP/AP up to 1080P@60fps AVS-P16(AVS+)/AVS-P2 jiZhun Profile up to 1080P@60fps MPEG-2 MP/HL up to 1080P@60fps(ISO-13818) MPEG-1 MP/HL up to 1080P@60fps(ISO-11172) Realvideo 8/9/10 up to 1080P WebM up to VGA Multiple language and multiple format sub-title video support MJPEG and JPEG unlimited pixe resolution decoding(ISO/IEC-10918) Supports JPEG thumbnail, scaling, rotation and transition effects Support *.mkv,*.wmv,*.mpg,*.mpeg,*.dat,*.avi,*.mov,*.iso,*.mp4,*.rm and *.jpg file formats |
|
| Software Extension | Support Google Play & APK install | |
| DLNA, Miracast Protocol | Support DLNA, Miracast Protocol | |
| Remote Control | Remote controller | |
| IM Software | Support Skype/QQ/MSN/GTALK (Depends on APK ） | |
| Office Software | WORD/EXCEL/PDF(Depends on APK install) | |
| Other Parameters: | ||
| Operation Temperature | 0~60℃ | |
| Storage Temperature | -10~60℃ | |
| Humidity Environment | 5%-90%(No condensation） | |
| Certificate | CE, FCC | |
| Package: | ||
| Dimensions | 117*117*18.5mm | |
| Net Weight | 300g | |
| Gift Box Size | 162*162*80mm | |
